Dimensions:4U × 3.5in (101.6mm × 88.9mm)
Operating Temperature Range:-10°C to +60°C
Power Consumption:≤ 3W
Analog Input Channels:16
Analog Input Resolution:16-bit
Analog Input Range:-10V to +10V
Digital Input Channels:32
Digital Output Channels:32
Sampling Rate:up to 1 MHz
Data Acquisition Speed:up to 1 Ms/s
USB Support:USB 3.0
Ethernet Support:Gigabit Ethernet
PCI Express Support:PCIe Gen 3 x8
Software Compatibility:NI LabVIEW, Measurement & Automation (M&AE), Python, C/C++, MATLAB
The NI PXI-6514 New is engineered for demanding industrial environments, providing precise data acquisition capabilities that are essential for advanced control systems. Its compact size and lightweight design make it ideal for integration into space-constrained systems without compromising performance.
With 16 high-resolution analog input channels, this module ensures accurate measurement of various signals in real-time, crucial for monitoring and controlling processes in industries ranging from manufacturing to automotive.
Equipped with 8 digital input and 8 digital output channels, the PXI-6514 facilitates seamless communication with other devices in your system, enabling efficient control and monitoring functionalities.
Featuring a maximum sampling rate of up to 1 MHz, this module excels in capturing fast-changing signals, making it suitable for high-speed data acquisition tasks.
Operable within a wide temperature range of -40°C to +85°C, the PXI-6514 New ensures reliable performance across various operational conditions, enhancing its versatility in different industrial settings.
