Number of Input Points:16
Rated Input Voltage:24V DC
Input Voltage Range:20 to 28V DC
Peak Voltage:30V DC
Input Current (24V DC):6mA
Common Connections:2 isolated points
Weight:20g
Operating Temperature:-20°C to +60°C
Storage Temperature:-40°C to +85°C
The Koyo D2-16ND3-2 DC Input Module is engineered to integrate seamlessly with the DirectLogic 205 series PLCs, providing a critical link in complex industrial control systems. With its sixteen sink/source inputs and two isolated commons, this module ensures efficient data collection and processing, enabling precise control over machinery and processes.
Each input channel is designed to withstand a wide range of voltages from 20 to 28 volts direct current (VDC), making it versatile for various applications. The peak voltage measurement at 30 VDC further enhances its reliability under fluctuating conditions.
At an operating voltage of 24 VDC, the module consumes a current of 6 milliamperes, demonstrating its energy-efficient design without compromising performance. This low current draw reduces power consumption, contributing to lower operational costs and environmental sustainability.
Monitoring specific voltage and current requirements is essential for optimal performance. Users must adhere to these specifications to ensure the module operates efficiently within their systems, avoiding potential damage due to misuse or incorrect configuration.
For detailed technical specifications and installation guidelines, please refer to the manufacturer’s documentation. Koyo offers comprehensive support materials to facilitate seamless integration and maximize the benefits of the D2-16ND3-2 in your industrial automation projects.
