Control Power nominal:20 VA
Control Power maximum:65 VA
Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz
Dimensions:Approximately 12 in H x 5 in W x 8 in L
Ground Current Input Frequency:20 to 100 Hz
Insulation Class:Class I
Phase Current Input Conversion:True RMS, 1.04 ms/sample
Weight:Approximately 4.5 kg
Optional Features:Metering Package
Communication Interfaces:Non-isolated RS232 port, RS485 port
Event Record Triggers:Power fail, Alarms, Self-test, Inhibit, Trip, Waveform Capture
Operating Range:-40°C (-40°F) to +60°C (140°F)
Storage Range:-40°C (-40°F) to +80°C (176°F)
The GE 369-HI-0-M-0-0 is a premium motor management relay engineered to deliver unparalleled performance in industrial environments. With a wide range of technical specifications and features, this relay ensures reliable monitoring and protection of motor systems. Key features include advanced waveform capture, event reporting, data logging, and built-in optional metering capabilities. This model is equipped with a non-isolated RS232 port and RS485 port for seamless communication, making it an ideal choice for industries requiring precise motor management solutions. Its compact design and versatile input ranges make it suitable for various applications, ensuring optimal performance and efficiency. The GE 369-HI-0-M-0-0 also offers robust insulation class I protection, ensuring long-lasting durability and reliability. By using the advanced metering capabilities, users can significantly lower maintenance costs and reduce troubleshooting time, making it a cost-effective solution for industrial motor management needs.
