Beckhoff EL4112 2-Channel Analog Output Terminal – Precision Control for Industry 4.0 Applications

Number of Channels:2

Analog Output Type:Voltage or Current

Supply Voltage:12…48V DC

Output Current:0…20mA

Signal Processing:Single-ended or differential

Resolution:12-bit

Operating Temperature:-25°C…+70°C

Enclosure Protection:IP20

Dimensions:98x58x36mm

Weight:Approx. 70g

Communication Interface:K-Bus

    The Beckhoff EL4112 is engineered with precision and reliability in mind, featuring a dual-channel design for simultaneous control of two independent processes. Its compatibility with EtherCAT ensures seamless integration into complex industrial networks, enhancing operational efficiency.

    Each channel supports a wide signal range, making it suitable for a variety of applications from temperature control to speed regulation. The terminal’s ability to handle both 0…10V and 4…20mA signals provides flexibility for diverse automation requirements.

    Built for industrial strength, the EL4112 operates within a broad temperature range (-25°C to +60°C), ensuring reliable performance under varying environmental conditions. Its panel mount design and robust wiring harness facilitate easy installation and maintenance.

    With a resolution of 12 bits, the EL4112 delivers highly accurate output values, critical for achieving precise control in critical manufacturing processes. Its low current consumption of typically 50mA minimizes energy usage and reduces system costs.

    Designed with user convenience in mind, the EL4112 supports a wide range of load resistances up to 750Ω, accommodating various types of loads without compromising performance. This versatility makes it an ideal choice for a multitude of industrial applications, from robotics to HVAC systems.
