Model Type:Ethernet IP Bridge Module
Manufacturer:Allen-Bradley
Communication Protocol:Ethernet/IP
Mounting Type:Chassis
Communication Speed:10/100 Mbps
Power Supply:3 mA at 24 VDC
Temperature Range:0 – 60 °C
Isolation:Continuous 30 V
Environmental Conditions:5 – 95% Non-Condensing Relative Humidity
Vibration Resistance:2 G
Shock Resistance:30 G
Enclosure Type:Open
Connection Cables:802.3 Compliant Shielded or Unshielded Twisted Pair
The Allen-Bradley 1756-EN2T Ethernet Module is a high-capacity IP module, engineered for superior performance in industrial environments. Its design ensures reliable communication speeds of up to 10/100 Mbps, facilitating efficient data exchange between ControlLogix systems and other devices on an EtherNet/IP network.
This module is equipped with a robust power supply capable of delivering 3 mA at 24 VDC, ensuring consistent operation under various environmental conditions. It is designed for compatibility with 802.3 compliant shielded or unshielded twisted pair cables, offering flexibility in installation and connectivity.
Featuring an open type enclosure, the 1756-EN2T supports easy maintenance and access to its components. It operates within a temperature range of 0 to 60°C, making it suitable for a wide array of industrial applications. The module is built to withstand challenging environmental conditions, including humidity levels from 5 to 95% non-condensing relative humidity, and can endure vibration up to 2G and shock up to 30G, ensuring durability in dynamic environments.
The inclusion of a USB port further enhances its functionality, providing an additional interface for configuration, monitoring, and software updates. This makes the 1756-EN2T a versatile component that streamlines integration into existing control systems, offering a cost-effective solution for improving network connectivity and operational efficiency in manufacturing and automation sectors.
Designed with user-friendliness in mind, the Allen-Bradley 1756-EN2T Ethernet Module simplifies complex network configurations, enabling technicians and engineers to quickly and easily establish connections between ControlLogix systems and EtherNet/IP networks. Its straightforward installation process and comprehensive documentation ensure minimal downtime and streamlined maintenance procedures.
