Input Voltage Range:100-240V AC
Operating Frequency:47-63Hz
Peak Output Current:10-150A
Torque Range:0.34-50.8Nm
Output Current Flow Max:500mA
Parameter File Type:AB
Module Weight:2.1Kg (4.6 lbs)
Dimensions:98.1mm x 32.77mm x 65.02mm
Operating Temperature:0-55 °C (32-131 °F)
Storage Temperature:-40-70 °C (-40-158 °F)
Relative Humidity:5-95% without condensation
Operating Shock:15 g (3 pulses, 11 ms)
Non-operating Shock:30 g (3 pulses, 11 ms)
Vibration Resistance:2.5 g
Compliance Standards:IEC, CE
The Allen Bradley 1398 DDM-019X Servo Drive is meticulously engineered for superior performance and reliability in demanding industrial environments. Its compact design and advanced control algorithms make it an ideal choice for applications requiring precise motor control.
Featuring a wide input voltage range of 100-240V AC and a robust peak output current capacity, this servo drive ensures compatibility with a variety of servo motors and applications, providing consistent power delivery and optimal performance.
With its compact size measuring 98.1 mm x 32.77 mm x 65.02 mm, the 1398 DDM-019X seamlessly integrates into confined spaces without compromising on functionality or performance. Its versatile input frequency range of 47-63Hz caters to different electrical systems, making it suitable for global applications.
The servo drive supports a torque range from 0.34 to 50.8Nm, enabling precise control over motor speed and direction. The output current flow maximum of 500mA ensures efficient power transfer to the connected servo motors, enhancing operational efficiency and reducing energy consumption.
Designed with durability in mind, the 1398 DDM-019X is rated to operate within a temperature range of 0-55 °C (32-131 °F), ensuring reliable performance under varying environmental conditions. Its ability to withstand relative humidity up to 95% without condensation makes it suitable for humid industrial settings.
