ABB AX645 Analog I/O Module 3BHB001914R1, High Performance Control Solution

Manufacturer:ABB

Model:AX645 3BHB001914R1

Module Type:Analog I/O

Dimensions (WxHxD):22.5 x 140 x 105 mm

Weight:0.6 kg

Operating Voltage:DC 24V

Current Consumption:≤50 mA

Input Signal Range:-10V to +10V

Output Signal Range:0V to 10V or 4mA to 20mA

Operating Temperature:-25°C to +70°C

Storage Temperature:-40°C to +85°C

Connectors:16-pin DIN Rail Mounting

IP Rating:IP20

Number of Channels:8 Input / 8 Output

Communication Protocol:Modbus RTU

Operating Frequency:50/60 Hz

    The ABB AX645 3BHB001914R1 Analog I/O Module is designed with cutting-edge technology, offering unparalleled scalability and flexibility, making it an ideal choice for a wide range of industrial applications.

    Featuring a robust design, this module ensures high reliability and long service life, even under harsh operating conditions. Its compact size and lightweight construction facilitate easy installation and maintenance.

    With multiple configurable input/output channels, the module supports various signal types, including voltage and current signals, providing flexibility for integration into different control systems.

    The power supply voltage range of 8..30VDC offers adaptability to different industrial environments, ensuring the module can function effectively in diverse settings.

    Efficient current consumption of up to 60mA per channel ensures minimal power usage, reducing energy costs without compromising performance. The operating temperature range from -25°C to +60°C guarantees reliable operation across a broad spectrum of industrial climates.
