ABB 3HAA3563-AMA/0: Serial Measurement Board for Precision Data Collection

Type:Serial Measurement Board

Model:3HAA3563-AMA/0

Series:ABB

Application Environment:Industrial

Operating Temperature Range:-25°C to +60°C

Data Transmission Protocol:RS-485

Maximum Data Rate:10 Mbit/s

Power Supply Voltage:DC 12V to 30V

Power Consumption:≤1W

Connector Type:M12

Number of Channels:8

Accuracy:+/-0.05% + 1LSB

Communication Distance:Up to 1500m

    This ABB 3HAA3563-AMA/0 serial measurement board is engineered for demanding industrial settings where precise and reliable data transfer is essential. It boasts an operating temperature range from -25°C to +60°C, making it suitable for various industrial environments.

    With a maximum data rate of 10 Mbit/s over RS-485 protocol, this board ensures fast and efficient communication between devices. Its compatibility with DC voltage from 12V to 30V provides flexibility in power supply options.

    Featuring a low power consumption of ≤1W, the board operates efficiently without adding significant energy demands to your system. The M12 connector type ensures robust and secure data connections.

    Equipped with 8 channels, the ABB 3HAA3563-AMA/0 is capable of measuring multiple signals simultaneously, enhancing its utility in complex industrial setups. The accuracy of +/-0.05% + 1LSB ensures reliability in data acquisition.

    With a communication distance of up to 1500m, this serial measurement board extends the reach of your data transfer capabilities, making it ideal for long-distance industrial automation projects.
