Module Type:Digital DC Output
Number of Channels:16
Input Voltage:24 Volts DC
Output Voltage Range:10-50 VDC
On-State Voltage Drop:1.2 V
Off-State Output Leakage:1 mA
Load Capacity:1 mA per channel
Current Rating:Backplane: 0.28 A, Continuous Current Per Output: 0.25 A @ 60°C
Continuous Current Per Module:4 A @ 60°C
Isolation Voltage:Communication Circuits: 500 VDC, Backplane: 1500 VAC
Enclosure Type:Open Type
Mounting:Chassis
Temperature Range:0-60°C
Environmental Conditions:5%-95% relative humidity non-condensing
The Allen-Bradley 1746-OG16 is meticulously designed for unparalleled performance in industrial automation environments, offering precise control over processes with its robust digital output capabilities.
Featuring a compact and efficient design, this module seamlessly integrates with SLC 500 systems, enhancing system reliability and efficiency.
With a high current rating per channel and continuous operation capability at 60°C, the 1746-OG16 ensures consistent performance under demanding conditions, making it ideal for applications requiring high output capacity.
Backed by Allen-Bradley’s commitment to quality and reliability, this module boasts exceptional isolation properties, ensuring effective separation of signals and protection against interference.
Easy to install and integrate, the open-type enclosure allows for flexible mounting options on various industrial setups, providing convenient access for maintenance and troubleshooting.
